Compliant with DMX512/1990 standard, with a maximum of 1024 DMX control channels. The optically isolated signal output can control up to 96 moving head lights or 96 dimming channels, compatible with Pearl light library.

Built-in pattern generator with 135 pre-programmed patterns, facilitating graphic trajectory control of moving head lights, such as circle, spiral, rainbow, chase and other effects. All pattern parameters (e.g., amplitude, speed, interval, wave, direction) can be set independently.

60 playback scenes for storing multi-step and single-step scenes; a maximum of 600 steps can be saved for multi-step scenes.

Backlit LCD screen with Chinese-English display function; data is retained after shutdown.

Support USB flash drive backup and firmware upgrade. Equipped with a professional gooseneck work light, suitable for indoor and outdoor performances.

Power Supply: AC 90-240V/50-60Hz

Dimensions: 485×420×105mm
